All You Need to Know About Centrifugal Pumps

All You Need to Know About Centrifugal Pumps

There are so many innovative things in everyone’s life that we ignore. Take the example of pumps; we know that this piece of engineering marvel helps us to transport liquid from one point to another. But we don’t give it a thought about their working mechanics and how they perform the task at hand. Now, when it comes to pumps, centrifugal pumps are one of the widely used pumps for industrial as well as domestic use. They are extensively used for supplying water for domestic use to their industrial usage in food, chemical, and beverage manufacturing.

To meet the multitude of purposes, different types of centrifugal pumps are used. There is  a wide range of centrifugal pumps that can suit a specific purpose for its domestic and industrial application. The main reason behind the centrifugal pump’s widespread use is its simple design, smooth flow rate, wide range of capacity, and easy maintenance. Furthermore, they are an excellent pumping option for the displacement of lower viscosity liquids with a high flow rate.

What is Centrifugal Pump?

A centrifugal pump is a mechanical device that moves a fluid by transferring rotational energy from one or more impellers or driven rotors. Fluid enters the impeller along its axis and is thrown out throughout its circumference by centrifugal force through the impeller’s vane tips. The impeller increases the velocity and pressure of the fluid while also directing it towards the pump output. The pump casing is designed to compress fluid entering the pump, guide it into the impeller, and then slow and regulate it before discharge.

Working Process:

A centrifugal pump runs by suctioning the liquid through its inlet pipe and directing it towards the impellers. These impellers then give momentum to the injected liquid through its spinning vanes, which in turn increases the liquid’s velocity. This liquid is then directed to its directed spot via a piping system.

There are many different types of centrifugal pumps based on their orientation, stages, and impeller designs. And choosing the right centrifugal pump is directly dependent on its construction, design, pressure, etc.

What Are The Main Features Of A Centrifugal Pump?

Centrifugal and positive displacement pumps are the two primary types of pumps. Centrifugal pumps, in contrast to displacement pumps, are typically designed for larger flows and lower viscosity liquids. Centrifugal pumps will account for 90% of the pumps in some chemical facilities. Positive displacement pumps, on the other hand, are favored in a variety of applications.

What Are The Advantages Of Centrifugal Pumps?

Because centrifugal pumps are ideally adapted for transferring large quantities of low viscosity liquids, they are often used to transport water, chemicals, and light fuels. One disadvantage is that centrifugal pumps may not perform as well for viscous or inconsistent liquids since the impeller must be immersed in liquid at all times to function properly. To avoid clogging, open impellers can be used to transport certain forms of solid debris in liquid, while chopper impellers can minimize the size of particles to ensure smooth operation.

The fundamental design of a centrifugal pump is extremely simple, despite the fact that every type of pump may be made more complex with extra features. They don’t need valves or pistons, and they have few moving components. As a result, they can be made out of a number of materials, ranging from plastic to stainless steel or bronze, depending on their intended use. When compared to other pump types, maintenance is usually low and uncomplicated.

Centrifugal pumps take up a tiny amount of space due to their straightforward design. This is one of the reasons why many people choose centrifugal water pumps in both domestic and industrial settings. If you have a limited amount of floor space, a centrifugal pump may be the best option.

What Are The Limitations Of A Centrifugal Pump?

The efficient operation of a centrifugal pump is dependent on the impeller rotating at a constant high speed. Centrifugal pumps become progressively inefficient with high viscosity feeds: there is more resistance and higher pressure is required to maintain a particular flow rate. Centrifugal pumps are best suited to pumping liquids with viscosities ranging from 0.1 to 200 cP at low pressures and large capacities.

Slurries like dirt or lubricants with a high viscosity can cause excessive wear and overheating, resulting in damage and premature failure. Positive displacement pumps, on the other hand, often run at much lower rates and are less prone to these issues.

The rapid speed of a centrifugal pump’s impeller can harm any pumped medium that is susceptible to shearing (such as emulsions, slurries, or biological liquids). In such instances, a positive displacement pump with a lower speed is desirable.

A further limitation is that, unlike a positive displacement pump, a centrifugal pump cannot provide suction when dry: it must initially be primed with the pumped fluid.  Centrifugal pumps are therefore not suited to any application where the supply is intermittent. Additionally, if the feed pressure is variable, a centrifugal pump produces a variable flow; a positive displacement pump is insensitive to change pressures and will provide a constant output. So, in applications where accurate dosing is required, a positive displacement pump is preferred.

Read more on Linquip

What Are The Main Applications For Centrifugal Pumps?

Centrifugal pumps are extensively used in industrial, agricultural, and home applications to pump water, solvents, organics, oils, acids, bases, and other ‘thin’ liquids. In fact, a centrifugal pump may be used in almost any application that involves low viscosity fluids.

Based on their application there are different types of centrifugal pumps available that are useful for different purposes. These centrifugal pumps are further differentiated based on their different stages, orientation, and mechanism.

Final Thoughts:

A centrifugal pump works by transferring rotational energy from one or more impellers, or driven rotors. The impeller raises the velocity and pressure of the fluid and directs it towards the pump exit. The centrifugal pump is straightforward to understand, operate, and maintain because of its basic design. The above-mentioned information will help you to understand the dynamics of centrifugal pumps and you can use this information to make a better decision.
